Cross Flow Fan

UF9060 Series

Frame: Steel with black painting
Impeller: Plastic & Aluminum
Bearing System: Ball bearing or sleeve bearing
Motor: Capacitor start-run or Shaded pole
Protection: Impedance-Protected or Thermally-Protected
Insulation Resistance: Above 100MΩ,DC 500V.
Dielectric Withstand Voltage AC1, 500V (50/60Hz) one minute
Safety Approval: CE, TUV. (UF9029 has UL, CUL approval)
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF9060CBP12HL UF9060CBP23HL
Rated Voltage 120 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 130/160 W 130/160 W
Rated Current 1/1.25 A 0.55/0.7 A
Locked Current 1.4/1.4 A 0.75/0.75 A
Speed 2150/2100 RPM 2150/2100 RPM
Maximum Air Flow 15.5/15 m3/min. 15.5/15 m3/min.
Maximum Air Flow 550/530 CFM 550/530 CFM
Maximum Pressure 9/11 mmH2O 9/11 mmH2O
Maximum Pressure 0.35/0.43 InchH2O 0.35/0.43 InchH2O
Noise 55/54 dB 55/54 dB
Weights 6 kg 6 kg
SAFETY APPROVAL
