Cross Flow Fan

UF9446 Series

Frame: Steel with black painting
Impeller: Plastic & Aluminum
Bearing System: Ball bearing or sleeve bearing
Motor: Capacitor start-run or Shaded pole
Protection: Impedance-Protected or Thermally-Protected
Insulation Resistance: Above 100MΩ,DC 500V.
Dielectric Withstand Voltage AC1, 500V (50/60Hz) one minute
Safety Approval: CE, TUV. (UF9029 has UL, CUL approval)
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF9446CBP12HL UF9446CBP23HL
Rated Voltage 120 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 43/50 W 43/50 W
Rated Current 0.4/0.42 A 0.2/0.23 A
Locked Current 0.63/0.63 A 0.31/0.31 A
Speed 1350/1550 RPM 1350/1550 RPM
Maximum Air Flow 8.5/10 m3/min. 8.5/10 m3/min.
Maximum Air Flow 300/354 CFM 300/354 CFM
Maximum Pressure 3.5/5 mmH2O 3.5/5 mmH2O
Maximum Pressure 0.14/0.2 InchH2O 0.14/0.2 InchH2O
Noise 48/53 dB 48/53 dB
Weights 3.6 kg 3.6 kg
SAFETY APPROVAL
