Cross Flow Fan

UF9029 Series

Frame: Steel with black painting
Impeller: Plastic & Aluminum
Bearing System: Ball bearing or sleeve bearing
Motor: Capacitor start-run or Shaded pole
Protection: Impedance-Protected or Thermally-Protected
Insulation Resistance: Above 100MΩ,DC 500V.
Dielectric Withstand Voltage AC1, 500V (50/60Hz) one minute
Safety Approval: CE, TUV. (UF9029 has UL, CUL approval)
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF9029CBP12HL UF9029CBP23HL
Rated Voltage 120 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 33/31 W 33/31 W
Rated Current 0.28/0.27 A 0.14/0.13 A
Locked Current 0.4/0.4 A 0.2/0.19 A
Speed 1350/1560 RPM 1350/1560 RPM
Maximum Air Flow 4.5/5 m3/min. 4.5/5 m3/min.
Maximum Air Flow 159/177 CFM 159/177 CFM
Maximum Pressure 2.2/3.3 mmH2O 2.2/3.3 mmH2O
Maximum Pressure 0.09/0.13 InchH2O 0.09/0.13 InchH2O
Noise 43/46 dB 43/46 dB
Weights 3 kg 3 kg
SAFETY APPROVAL
