Axial Fan

UF25GCB Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF25GCB11-H UF25GCB23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 68/96 W 70/98 W
Rated Current 0.62/0.88 A 0.32/0.45 A
Locked Current 1.16/1.16 A 0.6/0.6 A
Speed 2800/3200 RPM 2800/3200 RPM
Maximum Air Flow 20.2/23 m3/min. 20.2/23 m3/min.
Maximum Air Flow 713/812 CFM 713/812 CFM
Maximum Pressure 22.7/20.7 mmH2O 22.7/20.7 mmH2O
Maximum Pressure 0.9/0.82 InchH2O 0.9/0.82 InchH2O
Noise 62/65 dB 62/65 dB
Weights 2.3 kg 2.3 kg
SAFETY APPROVAL
