Axial Fan

UF92A Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF92A11-H UF92A23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 15/12 W 16/12 W
Rated Current 0.22/0.16 A 0.12/0.09 A
Locked Current 0.29/0.25 A 0.15/0.13 A
Speed 2800/3300 RPM 2800/3300 RPM
Maximum Air Flow 1.1/1.3 m3/min. 1.1/1.3 m3/min.
Maximum Air Flow 38/46 CFM 38/46 CFM
Maximum Pressure 5.6/8.1 mmH2O 5.6/8.1 mmH2O
Maximum Pressure 0.22/0.32 InchH2O 0.22/0.32 InchH2O
Noise 34/38 dB 34/38 dB
Weights 0.45 kg 0.45 kg
SAFETY APPROVAL
